Precision UV radiometer - Meteorological sensors

Precision UV radiometer - Meteorological sensors

ATMOS-meteo sells two models of precision UV radiometer. They measure with precision the amount of ultraviolet radiation. Each reference is specific to a range of UV (UV-A for and UV-B)

NetPilote création de site internet comité d'entreprise experts en sites dynamiques.

lundi 6 juillet 2020

Precision UV radiometer

Pour fermer, cliquez ici
Description

Description

These precision radiometers measure the amount of ultraviolet radiation that reach to the ground. Each of the two references is specific to a range of UV: the MS212A measure the UV - A (315-400 nm), while the MS212W has a sensor sensitive to UV - B (280-315 nm).

Product Code

Ref : MS-212A / MS-212W - Brand: EKO

Specifications

Mesure range
  • MS-212A version (UVA): 315 to 400 mm
  • MS-212W version (UVB): 280 to 315 mm
Output signals
  • MS-212A version (UVA): 0-1 VDC for 0-100 W.m²
  • MS-212W version (UVB): 0-1 VDC for 0-5 W.m²
Power supply

100-240 VAC (10-30 W)

Height 120 mm
Diameter 160 mm
Weight 1,1 kg
